To create the new curves, click the mouse when you are satisfied with what is displayed. However, by placing the cursor in desired areas, you should find that this method of allowing you to select the desired offset area allows for the offset of many very complex shapes.Īlso, remember that if the offset does not give you exactly what you want, you can easily use the Trim and Extend functions to make minor changes later. With large offset distances and collapsed areas, some unique results will occur if the cursor is placed in areas that should be removed.
If portions of your selected curves would collapse out or cross over one another given the current offset side and distance, the cursor location determines which area of offset curves is kept. The first two are fairly clear, but the third is also very important.
